derul low temperature resistant flexible cable | dedicated for refrigeration equipment China

derul low temperature resistant flexible cable | dedicated for refrigeration equipment

spécification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Renseignez-vous maintenant Produit suivant

INTRODUCTION

Typical uses of derul cold-resistant cables:

Connection and control cables are suitable for various electrical installations in dry or humid indoors, especially in industrial environments. As control and continuous flexible wires with a cross-section of 0.5mm2 and above, they are particularly suitable for use in machine tool manufacturing, complete equipment installation projects, power stations, heating and air conditioning installations, etc. In view of its special flexible design, it is also suitable for installation and fixed laying of free discontinuous reciprocating motion without stress relief and forced guidance.

derul cold-resistant cable cold-resistant cable product structure:

Conductor:Multi-strand finely twisted oxygen-free copper wire

Insulation:Special blend PVC

Inner lining:PP tape or aluminum foil Mylar wrapped shielding

Braiding:bare copper wire or tinned copper wire braiding

Sheath:oil-resistant,waterproof special mixed PVC

Cold-resistant cable technical parameters:

Test voltage:≥0.5mm2500

Working voltage:≥0.75mm300/500V

Minimum bending radius:fixed 6*cable outer diameter

Operating temperature:-70℃to+70℃(according to customer requirements)

Packing:in tray or roll

After-sales service:

We have always adhered to the tenet of"integrity-based,quality first"and serve our customers with integrity.With good reputation and excellent quality,we are based on the majority of users.The warranty is 24 months from the signing of the contract.If any quality problems arise,our company will solve them in time and realize"no returns and no exchanges".We welcome new and old friends from all over the world to come and purchase.

AVANTAGES

It is resistant to bending, abrasion, oil, softness, torsion resistance, tear resistance, electromagnetic wave interference resistance, flame retardant and water resistance, and has certain electrical insulation properties.

CAPACITÉ DE PERSONNALISATION

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Derul Cable est-il un fabricant ou une société commerciale ?

A: Derul Cable est un fabricant de câbles spécial basé à Shanghai.

Q: Le prix est-il négociable ?

A: Oui, le prix est négociable en fonction de la quantité achetée.

Q: Oui, le prix est négociable en fonction de la quantité achetée.

A: N’importe quelle quantité est OK à acheter pour le produit en stock. Pour les produits qui doivent être fabriqués après la commande, le MOQ est généralement de 100 à 200 m par type.

Q: Comment puis-je obtenir des échantillons ?

A: Après le paiement du coût potentiel, y compris le fret express et la confirmation de la dimension et de la structure du câble, nous organiserons l’échantillon et l’enverrons directement à votre porte.

Q: Le service OEM ou ODM est-il disponible ?

A: Les services OEM et ODM sont tous deux disponibles. Vous pouvez nous faire part de vos besoins et nous les évaluerons pour aller de l’avant.

Q: Quel est le temps de production habituel ?

A: Pour une quantité régulière, il faut généralement environ 15 à 25 jours pour produire.
