spécification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Renseignez-vous maintenant

INTRODUCTION

Derul PVC material flat cable |Application scope:

Suitable for laying in dry or humid indoors, mainly used for conveyors and lifting equipment (such as elevator accompanying lifting equipment, etc.), and can also be used as feeder cables for moving mechanical parts. These cables can also be exported in accordance with CE certification. (CE certification, model Complete specifications, customizable, national standard quality).

Derul PVC material flat cable|Product structure:

Rated voltage:1mm²and below U₀/U 300V/500V,1.5mm²and above U₀/U 450V/750V

Test voltage:1mm²and below U₀/U 2000V,1.5mm²and above U₀/U 2500V

Minimum bending radius:10×cable outer diameter

Temperature range;mobile installation:-5℃to 80℃

Fixed installation:-40℃to+80℃

Radiation resistance:up to 80×106 cJ/kg

Flame retardant properties:PVC self-extinguishing and flame retardant,test method B is in accordance with Part 804 of VDE0472 and IEC 60332-1

Insulation resistance:>20MΩ×km

No harmful substances,compliant with RoHS standards

This product complies with the requirements of EEC Directive 73/23(Low Voltage Directive)CE

Comply with BS standard EN50214

AVANTAGES

·Exceptionally oil resistant

·Chemical resistance

·High flexibility

·Wide operating temperature range

·Very small installation space

·Can be superimposed and installed

※Special customization can be provided for customers

CAPACITÉ DE PERSONNALISATION

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Derul Cable est-il un fabricant ou une société commerciale ?

A: Derul Cable est un fabricant de câbles spécial basé à Shanghai.

Q: Le prix est-il négociable ?

A: Oui, le prix est négociable en fonction de la quantité achetée.

Q: Oui, le prix est négociable en fonction de la quantité achetée.

A: N’importe quelle quantité est OK à acheter pour le produit en stock. Pour les produits qui doivent être fabriqués après la commande, le MOQ est généralement de 100 à 200 m par type.

Q: Comment puis-je obtenir des échantillons ?

A: Après le paiement du coût potentiel, y compris le fret express et la confirmation de la dimension et de la structure du câble, nous organiserons l’échantillon et l’enverrons directement à votre porte.

Q: Le service OEM ou ODM est-il disponible ?

A: Les services OEM et ODM sont tous deux disponibles. Vous pouvez nous faire part de vos besoins et nous les évaluerons pour aller de l’avant.

Q: Quel est le temps de production habituel ?

A: Pour une quantité régulière, il faut généralement environ 15 à 25 jours pour produire.
