YFFB flat cable for traveling and port machinery| Flat cable supplier-Shanghai DerulCable Price

YFFB flat cable for traveling and port machinery| Flat cable supplier-Shanghai Derul Cable

spécification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Renseignez-vous maintenant Produit suivant

INTRODUCTION

Derul YFFBG crane flat cable|Application scope:

Power transmission and control cables are widely used in mobile equipment such as cranes, trolleys, and transmission machinery. Such as metallurgy, electric power, ships, logistics transportation systems, and port machinery.

Derul YFFBG crane flat cable | Structure:

Conductor: Multi-stranded flexible oxygen-free copper wire conforms to DIN VDE 0295 level 5

Insulation: High-quality oil-resistant, flame-retardant PVC blend Color: Colored or coded cores with grounded yellow and green cores

Sheath: Premium oil-resistant, flame-retardant PVC blend Color: Black or gray

Derul YFFBG crane flat cable | Electrical characteristics:

Rated voltage: U0/U 300/500 V

Test voltage: U 2500V

Temperature range: ℃Mobile installation: -15℃～+70℃

Fixed installation: -30℃～+70℃

AVANTAGES

This product is cold-resistant, soft, wear-resistant, and oil-proof.

The bending radius is smaller than that of round cables, saving installation space.

Multiple cables can be overlapped and bundled.

When the core wires are arranged in a single row and in a straight line: the hanging length is >40m and the moving speed is >2m/s. It is recommended to add load-bearing steel wire or spun yarn.

When the core wires are arranged in plum blossom type twisting: hanging length > 80m and moving speed > 4-10m/s, it is recommended to add load-bearing steel wires.

CAPACITÉ DE PERSONNALISATION

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Derul Cable est-il un fabricant ou une société commerciale ?

A: Derul Cable est un fabricant de câbles spécial basé à Shanghai.

Q: Le prix est-il négociable ?

A: Oui, le prix est négociable en fonction de la quantité achetée.

Q: Oui, le prix est négociable en fonction de la quantité achetée.

A: N’importe quelle quantité est OK à acheter pour le produit en stock. Pour les produits qui doivent être fabriqués après la commande, le MOQ est généralement de 100 à 200 m par type.

Q: Comment puis-je obtenir des échantillons ?

A: Après le paiement du coût potentiel, y compris le fret express et la confirmation de la dimension et de la structure du câble, nous organiserons l’échantillon et l’enverrons directement à votre porte.

Q: Le service OEM ou ODM est-il disponible ?

A: Les services OEM et ODM sont tous deux disponibles. Vous pouvez nous faire part de vos besoins et nous les évaluerons pour aller de l’avant.

Q: Quel est le temps de production habituel ?

A: Pour une quantité régulière, il faut généralement environ 15 à 25 jours pour produire.
