Supply flexible low smoke halogen-free cable | China Derul brand manufacturer Company

Supply flexible low smoke halogen-free cable | China Derul brand manufacturer

spécification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Renseignez-vous maintenant

INTRODUCTION

China Derul brand low smoke halogen-free cable:

It is suitable for electrical connections in industrial automation, mechanical and electrical equipment, machine tools and other mechanical equipment, logistics transmission systems, production lines and other control systems. It is especially suitable for fixed installation in dry or humid indoor environments in industrial environments. It can also be used for non-continuous reciprocating motion without Mobile installation with forced traction. The cable has good flexibility. The sheath is made of low-smoke halogen-free materials and is suitable for crowded places with environmental protection requirements, such as airports, train stations, commercial buildings, hospitals and other public places. Low smoke after burning, higher flame retardant level, safer.

China Derul brand product structure：

Conductor: Multiple strands of finely twisted bare copper wire, conforming to IEC 60228/VDE 0295, Category 5 conductor

Insulation: Special halogen-free mixed environmentally friendly materials

Core wire: The core wire is twisted into a cable, and the color of the core wire conforms to VDE 0293

JZ black core wire, white digital code, with yellow and green wires

JB color core wire, with yellow and green wires

OZ black core wire with white digital code, without yellow and green wires

OB color core wire, without yellow and green wires

Outer sheath: Special halogen-free mixed environmentally friendly material

Outer sheath color: gray

AVANTAGES

Working voltage: 300/500V

Test voltage: 2000V

Insulation resistance: ≥20MΩ/km (20°C)

Small bending radius: mobile installation: approx. 15x D (cable outer diameter)

Fixed installation: approx. 4x D (cable outer diameter)

Operating temperature: mobile installation -5°C to +70°C

Fixed installation -30°C to +80°C

Flame retardant properties: Conforms to VDE 0472 – 804 Part B Class B test standards, and IEC 60332-1

CAPACITÉ DE PERSONNALISATION

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Derul Cable est-il un fabricant ou une société commerciale ?

A: Derul Cable est un fabricant de câbles spécial basé à Shanghai.

Q: Le prix est-il négociable ?

A: Oui, le prix est négociable en fonction de la quantité achetée.

Q: Oui, le prix est négociable en fonction de la quantité achetée.

A: N’importe quelle quantité est OK à acheter pour le produit en stock. Pour les produits qui doivent être fabriqués après la commande, le MOQ est généralement de 100 à 200 m par type.

Q: Comment puis-je obtenir des échantillons ?

A: Après le paiement du coût potentiel, y compris le fret express et la confirmation de la dimension et de la structure du câble, nous organiserons l’échantillon et l’enverrons directement à votre porte.

Q: Le service OEM ou ODM est-il disponible ?

A: Les services OEM et ODM sont tous deux disponibles. Vous pouvez nous faire part de vos besoins et nous les évaluerons pour aller de l’avant.

Q: Quel est le temps de production habituel ?

A: Pour une quantité régulière, il faut généralement environ 15 à 25 jours pour produire.
