ODM. Low temperature resistant cable-cold resistant reel cable-China Deru Cable Manufacturer

Low temperature resistant cable-cold resistant reel cable-China Deru Cable Manufacturer

spécification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Renseignez-vous maintenant

INTRODUCTION

Deru low temperature resistant reeling cable-cold resistant cable|Application scope:

Deru low-temperature-resistant reel cables have excellent low-temperature resistance, containment resistance, and anti-freeze properties. They are used in mechanical equipment in low-temperature and cold environments. They are used as frequently mobile electrical connection and installation cables. They maintain good soft movement ability at low temperatures, which provides good protection for equipment. It provides necessary guarantees for operation and is widely used in various mechanical equipment such as outdoor gantry cranes, lifting grabs, and tire-type cranes to meet the needs of frequent and repeated winding, dragging, and mobile installations in low-temperature and cold environments.

Deru low temperature resistant reeling cable - cold resistant cable | product design description:

*Special low-temperature and cold-resistant materials are selected for the cable insulation and sheath material design to ensure the cable's frequent mobile installation applications in low-temperature and cold situations. The selection of low-temperature resistance grades that meet the needs ensures that the cables can be widely used in low-temperature situations of different levels. The cables will not harden or crack, and still maintain excellent soft movement capabilities;

*The oxygen-free bare copper wire conductor stranding design ensures that the cable has excellent conductive properties and excellent flexibility;

*High-strength insulation and sheath design, the cable has excellent tensile strength; and the use of filling and braiding tensile reinforcement design ensures that the cable has excellent mechanical tensile load performance under frequent movement;

*The double-sheath reinforced structure design adopted, especially the double-sheath reinforcement under the special twist-free core wire twisted cable structure design, the cable has excellent torsion resistance performance, ensuring that the cable will not twist or break under frequent movement. Solve problems such as rotation and deformation and improve the durability of the cable;

*The selection and application of sheath materials that meet the needs ensure the application performance requirements of cables in different complex working conditions in low temperature and cold situations, and are wear-resistant, oil-resistant, waterproof, acid-alkali corrosion-resistant, UV-resistant, and sunlight-resistant Excellent performance in aging, cracking, heat resistance and flame retardancy;

*Multiple specifications and structures can be designed on demand. Power core wires, control core wires, data signal wires, optical fibers and other core wires can be bundled and designed on demand to meet the needs of multi-functional electrical connection installation applications under different equipment;

*For reel/reel systems in low-temperature and cold environments, our company can also design low-temperature-resistant flat cables. Compared with round cables, they have a smaller bending radius to meet the requirements of reels/reels in low-temperature and cold environments. The flat moving cables of the system are needed;

Deru low temperature resistant reeling cable-cold resistant cable|Main product parameters:

Rated voltage: 0.6/1KV and below voltage range;

Test voltage: 3500V/5min;

Bending radius: 8~10xD (mobile installation);

Low temperature resistance temperature range: -20℃, -40℃ and other different low temperature levels can be customized (for lower temperature requirements, please call for consultation);

Comply with certification: CE RoHS;

AVANTAGES

Specifically designed for large and medium-sized mobile machinery and equipment operating in low-temperature environments. Special materials with excellent low-temperature resistance are used as cable insulation and sheath designs to ensure that the cables still maintain excellent soft movement performance in low-temperature and cold environments and do not become hard or hard. It is non-cracking and anti-freezing, allowing the cable to withstand frequent retraction, dragging and moving of the reel/reel system even in low-temperature and cold environments. It is especially suitable for outdoor occasions with low-temperature and cold temperatures in winter, especially northern outdoor and high-altitude cold environments. Low temperature, etc., used for large and medium-sized mobile mechanical equipment with reel/reel coiling device system, used for power supply and control connection applications during equipment operation.

CAPACITÉ DE PERSONNALISATION

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Derul Cable est-il un fabricant ou une société commerciale ?

A: Derul Cable est un fabricant de câbles spécial basé à Shanghai.

Q: Le prix est-il négociable ?

A: Oui, le prix est négociable en fonction de la quantité achetée.

Q: Oui, le prix est négociable en fonction de la quantité achetée.

A: N’importe quelle quantité est OK à acheter pour le produit en stock. Pour les produits qui doivent être fabriqués après la commande, le MOQ est généralement de 100 à 200 m par type.

Q: Comment puis-je obtenir des échantillons ?

A: Après le paiement du coût potentiel, y compris le fret express et la confirmation de la dimension et de la structure du câble, nous organiserons l’échantillon et l’enverrons directement à votre porte.

Q: Le service OEM ou ODM est-il disponible ?

A: Les services OEM et ODM sont tous deux disponibles. Vous pouvez nous faire part de vos besoins et nous les évaluerons pour aller de l’avant.

Q: Quel est le temps de production habituel ?

A: Pour une quantité régulière, il faut généralement environ 15 à 25 jours pour produire.
