ROV zero buoyancy cable | multi-core single mode fiber plus power cord

ROV zero buoyancy cable | multi-core single mode fiber plus power cord - Derul Cable

spécification

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

Renseignez-vous maintenant Produit suivant

INTRODUCTION

Derul Zero Buoyancy Optical Ribbon Optoelectronic Composite Cable (underwater cable) | Product Application:

DeRu Zero Buoyancy Optoelectronic Composite Cables are mostly used as cables for large-scale industrial-grade underwater robots or underwater equipment, and can carry out long-distance optical and electrical transmission.

Derul Zero Buoyancy Optical Ribbon Optoelectronic Composite Cable|Product Structure:

Core conductor: multi-strand finely twisted oxygen-free copper/anti-corrosion tinned copper wire core can be customized

Number of wire cores per square: 1.5/2.5 can be customized according to customer requirements

Insulation: Seawater-proof mixed material

Optical fiber: 1-99 cores optional

Armor: Yes

Tensile structure: high-strength tensile Kevlar

Tensile grade: 50/100/200/500/1000KG

Waterproof level: 100/200/300/500/1000M

Shielding layer: tinned copper braid or aluminum foil wrapping (optional)

Wrapping material: non-woven fabric

Outer sheath: imported PU zero-buoyancy foam (polyurethane outer sheath can be added if the environment requires it)

Color: yellow/others can be customized

Comply with certification: CE/ROHS

AVANTAGES

Conventional anti-(sea) water cables will sink in (sea) water because their density is greater than the underwater density, which seriously affects the operation of underwater equipment. However, zero-buoyancy cables can maintain the same density in (sea) water without sinking. Reduce the impact on equipment operation. The outer diameter of the cable is small, the overall softness, tensile resistance, wear resistance, bending resistance, not easy to twist and knot. It can withstand 100-10000KG (optional), high strength and water pressure resistance, and can be used in water depths of 100- 1000 meters (optional).

CAPACITÉ DE PERSONNALISATION

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

FAQ

Q: Derul Cable est-il un fabricant ou une société commerciale ?

A: Derul Cable est un fabricant de câbles spécial basé à Shanghai.

Q: Le prix est-il négociable ?

A: Oui, le prix est négociable en fonction de la quantité achetée.

Q: Oui, le prix est négociable en fonction de la quantité achetée.

A: N’importe quelle quantité est OK à acheter pour le produit en stock. Pour les produits qui doivent être fabriqués après la commande, le MOQ est généralement de 100 à 200 m par type.

Q: Comment puis-je obtenir des échantillons ?

A: Après le paiement du coût potentiel, y compris le fret express et la confirmation de la dimension et de la structure du câble, nous organiserons l’échantillon et l’enverrons directement à votre porte.

Q: Le service OEM ou ODM est-il disponible ?

A: Les services OEM et ODM sont tous deux disponibles. Vous pouvez nous faire part de vos besoins et nous les évaluerons pour aller de l’avant.

Q: Quel est le temps de production habituel ?

A: Pour une quantité régulière, il faut généralement environ 15 à 25 jours pour produire.
